Branoa, Threaded diaphragm valves, weir type

BRANOA® Threaded diaphragm valves

threaded weir type diaphragm valves Construction : Weir type diaphragm valves
Body material : Cast iron, Stainless steel,...
Diaphragm material : Natural rubber, EPDM, NBR, FKM, Silicone...
Class : PN10, PN20
Sizes : Up DN10 to DN80
End connections : Threaded: BSP, NPT
Lining material : Ebonite, Butyl, Halar, Rilsan, PVDF, ETFE, PFA, PTFE...
Title Reference Material Standards PN DN PDF
Branoa Acier PN10/16 103300 ACIER Passage Courbé / GAZ ou NPT 10/16 DN15 à DN80 B335.pdf
Branoa Fonte FT PN10/16 103100 FONTE FT Passage Courbé / GAZ ou NPT 10/16 DN15 à DN80 B335.pdf
Branoa Fonte GS PN10/16 103200 FONTE GS Passage Courbé / GAZ ou NPT 10/16 DN15 à DN80 B335.pdf
Branoa Inox 304 PN10/16 103400 INOX 304 Passage Courbé / GAZ ou NPT 10/16 DN15 à DN80 B335.pdf
Branoa Inox 316 PN10/16 103500 INOX 316 Passage Courbé / GAZ ou NPT 10/16 DN15 à DN80 B335.pdf
